Precision gearmotors
SLM worm gear motor
Worm gear motor is precision worm gearbox with adapter and asynchronous electric motor. In the power range from 0.18 to 9.0 kW. Gear ratio range 5:1 – 83:1. Max. output torque 10,500 Nm. 8 groups of housing sizes from 40 to 100 mm. Standard rotational clearance 30 arcmin, reduced 6 – 10 arcmin. Cast iron housing. Optional anti-corrosion version, with brake, fan, encoder.
VLM bevel gearmotor
Bevel, multi-shaft, right-angle gearbox with electric, asynchronous motor. Power range of bevel geared motors from 0.12 to 30.0 kW. Small gear ratios: 1:1, 2:1, 3:1, 4:1, 5:1, and 6:1. Maximum torque up to 2,310 Nm. Eight housing size groups from 65 to 260 mm. Standard backlash < 30 arcmin, reduced backlash < 6–10 arcmin. Cast iron or stainless steel housing. The bevel gear motor is optionally available with brake, fan, encoder, frequency inverter, anti-corrosion finish, stainless steel version, and ATEX explosion-proof design.
K-IE3D bevel gearmotor
Precision K bevel gearbox with 3-phase asynchronous electric motor. Power range 0.12 – 30 kW. Gear ratio range 4:1 – 381:1. Max torque 6.5 – 13,970 Nm. Standard backlash 10 – 12 arcmin, reduced backlash class II: 4 – 6 arcmin, class I: 1.5 – 3.0 arcmin. Efficiency 94 – 97%. Energy efficiency class IE3. Bevel geared motor optionally with encoder, brake, fan, frequency converter, Atex explosion-proof and anti-corrosion version.
F-IE3D flat gearmotor
Precision F parallel shaft gearbox with 3-phase asynchronous electric motor in the power range 0.12 – 7.5 kW. Gear ratio range 4.3:1 – 547:1. Maximum torque 5.1 – 1,338 Nm. Standard backlash 10 – 11 arcmin, reduced 5 – 6 arcmin. Efficiency 96 – 97%. Energy efficiency class IE3. Cast iron housing. Parallel shaft geared motor optionally with encoder, brake, fan, frequency converter, Atex explosion-proof and anti-corrosion version.
C-IE3D helical gearmotor
Helical gearbox with 3-phase asynchronous electric motor without adapter and coupling. Helical gearmotors in power range 0.12 – 30 kW. Ratio range 2:1 – 274:1. Low backlash 10 – 20 arcmin. High efficiency 96 – 97%. Energy efficiency class IE3. Helical geared motor optionally with encoder, brake, fan, inverter, Atex explosion-proof and anti-corrosion execution.
